NEW QUESTION # 27
In OSPFv2, which route characteristic is used to determine the best path?
- A. cost
- B. jitter
- C. packet loss
- D. delay
Answer: A
Explanation:
Explanation
In OSPFv2, the route characteristic that is used to determine the best path is the cost. The cost is a metric that represents the link bandwidth, delay, reliability, or other factors. The cost is inversely proportional to the bandwidth, meaning that a higher bandwidth link has a lower cost. The cost of a route is calculated by adding the costs of all links along the path. OSPFv2 uses the following formula to calculate the cost of an interface:
Cost = Reference bandwidth / Interface bandwidth in bps
The reference bandwidth is a constant value that can be configured by the network administrator. By default, it is 100 Mbps. The interface bandwidth is the actual bandwidth of the interface in bits per second. For example, if an interface has a bandwidth of 10 Mbps, its cost would be 100 Mbps / 10 Mbps = 101415.
OSPFv2 does not use jitter, packet loss, or delay as route characteristics to determine the best path. Jitter is the variation in latency or delay between packets. Packet loss is the percentage of packets that are dropped or corrupted during transmission. Delay is the time it takes for a packet to travel from source to destination. These characteristics are not part of the OSPFv2 protocol and are not advertised in OSPFv2 LSAs1617.
References: OSPF Metric cost Calculation Formula Explained - ComputerNetworkingNotes, OSPF Cost - OSPF Routing Protocol Metric Explained - Study-CCNA, Open Shortest Path First - Wikipedia, OSPF Metric
= Cost - Cisco
NEW QUESTION # 28
What is the CLI command to obtain the software version in Ericsson Router 6000 products?
- A. show log
- B. show sysstat
- C. show release
- D. show version
Answer: D
Explanation:
Explanation
The CLI command to obtain the software version in Ericsson Router 6000 products is show version. This command displays information about the software release, the hardware model, the serial number, the uptime, and the boot image of the router. References: [ERICSSON SMARTEDGE 600 HARDWARE MANUAL Pdf Download | ManualsLib], Ericsson Router 6000 Series - Ericsson
NEW QUESTION # 29
Review the exhibit.
Referring to the exhibit, which two Ericsson routers support the 100GE interface? (Choose two.)
- A. Router 6471
- B. Router 6675
- C. Router 6672
- D. Router 6273
Answer: B,C
Explanation:
Explanation
Referring to the exhibit, the two Ericsson routers that support the 100GE interface are Router 6675 and Router
6672. The 100GE interface is a high-speed Ethernet interface that operates at 100 gigabits per second. The Ericsson Router 6000 series is a family ofrouters that provide IP transport for mobile and fixed networks. The Router 6675 is a 5G combined access and E-RAN switch with 100GE interfaces and 320Gb forwarding capacity. The Router 6672 is a high-capacity metro aggregation router with 100GE interfaces and 1.6Tb forwarding capacity12.
References: Router 6000 Series - Ericsson, New Ericsson Router 6000 series couples radio and IP transport for
5G future - Global Brands Magazine
NEW QUESTION # 30
An operator wants to ensure that they can differentiate their traffic types for the purpose of prioritization in their Ethernet LAN and IP/MPLS backbone.
Which three fields would be used? (Choose three.)
- A. ECN
- B. Traffic Class (TC)
- C. VID
- D. PCP
- E. DSCP
Answer: B,D,E
Explanation:
Explanation
To differentiate traffic types for the purpose of prioritization in their Ethernet LAN and IP/MPLS backbone, an operator can use the following three fields:
Traffic Class (TC): This is a 3-bit field in the MPLS label that can be used to indicate the priority or class of service (CoS) of the packet. The TC field can be mapped to the DSCP field in the IP header or the PCP field in the Ethernet header. The TC field can be used by MPLS routers to apply different per-hop behaviors (PHBs) such as queuing, scheduling, and dropping policies to different traffic classes12.
DSCP: This is a 6-bit field in the IP header that can be used to mark packets according to the differentiated services (DiffServ) model. The DSCP field can indicate the per-hop behavior (PHB) that the packet should receive at each router along its path. The DSCP field can be mapped to the TC field in the MPLS label or the PCP field in the Ethernet header. The DSCP field can be used by IP routers to provide QoS for different traffic types34.
PCP: This is a 3-bit field in the Ethernet header that can be used to mark packets according to the IEEE
802.1Q standard. The PCP field can indicate the priority or class of service (CoS) of the packet on an Ethernet LAN. The PCP field can be mapped to the TC field in the MPLS label or the DSCP field in the IP header. The PCP field can be used by Ethernet switches to provide QoS for different traffic types56.
References: MPLS Traffic Engineering - DiffServ-Aware Traffic Engineering, MPLS Traffic Engineering - DiffServ-Aware Traffic Engineering Configuration Guide, Differentiated services - Wikipedia, DSCP and Precedence Values - Cisco, 802.1Q VLAN IDs and Ethernet Interface Types - Juniper Networks, Introduction to Virtual LANs (VLANs) and Tagging - Ubiquiti Support and Help Center
NEW QUESTION # 31
Which mismatched field would cause an IS-IS adjacency between two routers to fail?
- A. MTU
- B. Context
- C. SysID
- D. SEL
Answer: A
Explanation:
Explanation
MTU mismatch would cause an IS-IS adjacency between two routers to fail. MTU stands for maximum transmission unit, which is the maximum size of a packet that can be transmitted on a link. IS-IS hellos are padded to the full MTU size, partly to allow a router to implicitly communicate its MTU to its neighbors. If two routers have different MTUs on their interfaces, they will not be able to exchange hellos properly, and their adjacency will not form or will be dropped34. To solve this problem, the MTUs on both interfaces must be configured to match.
SEL, context, and SysID are not fields that would cause an IS-IS adjacency failure. SEL stands for selector, which is a one-octet field that identifies the network layer service to which a packet should be sent. For IS-IS routers, the SEL must always be 005. Context is not a field in IS-IS packets, but rather a term used to describe the scope of routing information in different levels or areas6. SysID stands for system identifier, which is a six-octet field that uniquely identifies a router within an area. SysID does not have to match between two routers for them to form an adjacency7.
References: MTU Mismatch Problem in IS-IS - Cisco, IS-IS adjacency is not formed due to MTU mismatch - Cisco Community, IS-IS NSAP address - Cisco Community, Understanding IS-IS Routing Contexts - Juniper Networks, IS-IS - Nokia
NEW QUESTION # 32
Which two features does IPsec provide? (Choose two.)
- A. controlling the path through the network
- B. protecting the length of packets from discovery
- C. hiding the content of packets from observation
- D. protecting packets from modification
Answer: C,D
Explanation:
Explanation
IPsec provides two main features: protecting packets from modification and hiding the content of packets from observation. IPsec protects packets from modification by using cryptographic algorithms to generate and verify message authentication codes (MACs) or digital signatures for each packet. These mechanisms ensure that the packets have not been tampered with or altered in transit by unauthorized parties. IPsec hides the content of packets from observation by using encryption algorithms to scramble the payload of each packet. This prevents eavesdroppers or interceptors from reading or analyzing the data carried by the packets12.
References: What is IPsec? | How IPsec VPNs work | Cloudflare, IPsec - Wikipedia
NEW QUESTION # 33
In a company network, a host sends an Ethernet frame destined to the address FF:FF:FF:FF:FF:FF.
What will an Ethernet switch do with this frame?
- A. It will forward the frame to all ports.
- B. It will forward the frame to only one port.
- C. It will drop it.
- D. It will send the frame only to management port.
Answer: A
Explanation:
Explanation
An Ethernet switch will forward the frame to all ports when the destination address is FF:FF:FF:FF:FF:FF.
This is because this address is the broadcast MAC address, which means that the frame is intended for all devices on the same LAN segment. The switch does not need to look up its MAC address table to find a matching entry for this address, but simply floods the frame out of all ports except the one where it received the frame. This way, the frame reaches every device on the LAN segment, regardless of their MAC addresses. References: Ethernet - Wireshark, Broadcast MAC Address - omnisecu.com
NEW QUESTION # 34
For IP destinations not found in the IS-IS Level 1 database, the Level 1 router must forward packets to the nearest Level 1-Level 2 router with which set?
- A. overload bit
- B. options bit
- C. attach bit
- D. status bit
Answer: C
Explanation:
Explanation
For IP destinations not found in the IS-IS Level 1 database, the Level 1 router must forward packets to the nearest Level 1-Level 2 router with the attach bit set. The attach bit is a flag in the IS-IS Level 1 LSP that indicates that the router is also a Level 2 router and can reach destinations outside the Level 1 area. The Level
1 router will install a default route pointing to the nearest Level 1-Level 2 router with the attach bit set. This way, the Level 1 router can forward packets to other areas without having to maintain a full Level 2 database. References: Ericsson IP Networking - Routing Protocols, Configure Attach Bit Set - Cisco
NEW QUESTION # 35
What network information is, without additional configuration, shared between two iBGP neighbors by default?
- A. BGP routes learned from eBGP neighbors
- B. IP address information from all directly connected interfaces
- C. IP address information of loopback interfaces
- D. BGP routes learned from an OSPF neighbor
Answer: A
Explanation:
Explanation
iBGP works by exchanging routing information between two or more routers within an AS. Each router sends its own routing table to its neighbors, which contains information about the networks it knows and how they can be reached from that router. By default, iBGP neighbors only share BGP routes learned from eBGP neighbors, which are routers in different ASes. This is because iBGP assumes that all routers within an AS have consistent internal routing information provided by an IGP, such as OSPF or IS-IS. Therefore, iBGP neighbors do not need to share IP address information of loopbackinterfaces or directly connected interfaces, unless explicitly configured to do so by using commands such as neighbor update-source or network.
References: iBGP Ultimate Guide | How iBGP Is Different From eBGP, Ericsson IP Networking - Routing Protocols
NEW QUESTION # 36
What is the correct abbreviation for the IP address: BFEA:DACA:0000:0000:9390:0000:0000:D91?
- A. BFEA:DACA::9390:0:D91
- B. BFEA:DACA::9390::D91
- C. BFEA:DACA::D91/6
- D. BFEA:DACA::9390:0:0:D91
Answer: A
Explanation:
Explanation
The correct abbreviation for the IP address BFEA:DACA:0000:0000:9390:0000:0000:D91 is BFEA:DACA::9390:0:D91. IPv6 addresses are represented in hexadecimal notation, with eight 16-bit segments separated by colons. To simplify the address representation, IPv6 supports two types of abbreviations. The first abbreviation allows us to skip leading zeros within a segment, while the second abbreviation allows us to drop one or more consecutive segments that contain only zeros, using a double colon (::) instead. However, the double colon can be used only once in an address, to avoid ambiguity34.
References: IPv6 Address Types, Notation, and Structure Explained, IPv6 address - Wikipedia
NEW QUESTION # 37
Review the exhibit.
A service provider wants to provide L3VPN for two customers (indicated by red and green in the exhibit).
Referring to the exhibit, which statement is correct?
- A. MP-BGP should be configured on all the service provider's routers (Ps and PEs).
- B. The service provider's P routers are not aware of the customers' routes.
- C. The two customers cannot use overlapping IP prefixes.
- D. LDP must be configured between PE and CE
Answer: B
Explanation:
Explanation
Referring to the exhibit, the correct statement is that the service provider's P routers are not aware of the customers' routes. This is because P routers only need to forward MPLS packets based on their labels, without looking into their IP headers or VPN information. The P routers do not have any VRFs configured for the customers, nor do they participate in MP-BGP sessions with other PE routers. The PE routers are responsible for maintaining VRFs for each customer and for exchanging VPN routes with other PE routers using MP-BGP910.
References: Layer 3 VPNs (L3VPN) - Cisco, MPLS VPN - Wikipedia
NEW QUESTION # 38
Which protocol would be used to bundle multiple Ethernet ports into a virtual link with an aggregated bandwidth?
- A. RSTP
- B. VRRP
- C. LACP
- D. ERP
Answer: C
Explanation:
Explanation
The protocol that would be used to bundle multiple Ethernet ports into a virtual link with an aggregated bandwidth is LACP, which stands for Link Aggregation Control Protocol. LACP is a protocol that allows two or more devices to negotiate the formation of a link aggregation group (LAG), also known as an EtherChannel or a port channel. A LAG combines multiple physical links into one logical link that provides increased bandwidth, load balancing, and redundancy. LACP is defined in IEEE 802.3ad and 802.1AX standards12.
References: Link Aggregation Control Protocol - Wikipedia, What is "link aggregation" and how does it benefit your network? | PC Gamer
NEW QUESTION # 39
Which two statements are correct for LDP? (Choose two.)
- A. LSRs send ICMP hello messages for neighbor discovery
- B. LSRs use UDP for session establishment.
- C. LSRs use TCP to negotiate LDP session parameters.
- D. LSRs send UDP hello messages for neighbor discovery.
Answer: C,D
Explanation:
Explanation
Two statements that are correct for LDP are:
LSRs send UDP hello messages for neighbor discovery. LDP is a protocol that distributes labels for MPLS forwarding along the shortest path calculated by an IGP. LDP uses two types of messages:
discovery messages and session messages. Discovery messages are used to discover and maintain adjacency with other LSRs that support LDP. Discovery messages are sent as UDP datagrams to the well-known multicast address 224.0.0.2 (all routers on this subnet) on port 64634.
LSRs use TCP to negotiate LDP session parameters. Session messages are used to establish, maintain, and terminate LDP sessions between LSRs. Session messages are also used to exchange label mappings, notification messages, and keepalive messages. Session messages are sent as TCP segments to port
64634.
References: Ldp | Microsoft Learn, Label Distribution Protocol - Wikipedia
NEW QUESTION # 40
Review the exhibit.
Given the routing table shown in the exhibit, what is the next-hop to reach the host 192.168.1.129?
- A. 10.126.131.251
- B. 10.126.131.250
- C. 10.126.131.248
- D. 10.126.131.252
Answer: B
Explanation:
Explanation
The next-hop to reach the host 192.168.1.129 is 10.126.131.250. This can be determined by looking at the routing table in the exhibit. The host 192.168.1.129 falls within the range of the network 192.168.1.64/26, which has a next-hop of 10.126.131.250. References: Ericsson IP Networking - IP Addressing, Software Installation and Upgrade Overview (Junos OS)
NEW QUESTION # 41
Which router function advertises external routes in OSPF?
- A. ASBR
- B. ABR
- C. backbone router
- D. designated router
Answer: A
Explanation:
Explanation
The router function that advertises external routes in OSPF is ASBR, which stands for Autonomous System Boundary Router. An ASBR is a router that connects an OSPF domain to another routing domain, such as another OSPF domain or a different routing protocol domain. An ASBR can redistribute routes from other routing domains into OSPF as external routes, which are carried in type 5 or type 7 LSAs. External routes have two types: E1 and E2. E1 routes include the cost from the ASBR to the destination, while E2 routes only include the cost advertised by the ASBR34.
References: OSPF External Routes IpCisco, OSPF External Route selection algorithm - Cisco Community
NEW QUESTION # 42
What is the function of LSR from an LDP perspective?
- A. The LSR distributes packets of FEC to its LDP peers.
- B. The LSR distributes labels of FEC to its LDP peers.
- C. The LSR distributes packets of LDP to its FEC peers.
- D. The LSR distributes labels of LDP to its FEC peers.
Answer: B
Explanation:
Explanation
The function of LSR from an LDP perspective is to distribute labels of FEC to its LDP peers. LSR stands for Label Switching Router, which is a router that forwards packets based on labels rather than IP addresses in an MPLS network. LDP stands for Label Distribution Protocol, which is a protocol that distributes labels for MPLS forwarding along the shortest path calculated by an IGP. FEC stands for Forwarding Equivalence Class, which is a group of packets that are forwarded in the same manner by an LSR. An LSR uses LDP to advertise the label mappings for each FEC to its LDP peers, which are other LSRs that have established an LDP session with it12.
References: Ldp | Microsoft Learn, Label Distribution Protocol - Wikipedia
NEW QUESTION # 43
What is the subnet address for 10.57.126.156/29?
- A. 10.57.126.156
- B. 10.57.126.152
- C. 10.57.126.144
- D. 10.57.126.0
Answer: B
Explanation:
Explanation
The subnet address for 10.57.126.156/29 is 10.57.126.152. To find the subnet address, we need to perform a bitwise AND operation between the IP address and the subnet mask. The subnet mask for /29 is
255.255.255.248, which in binary is 11111111.11111111.11111111.11111000. The IP address in binary is
00001010.00111001.01111110.10011100. The result of the AND operation is
00001010.00111001.01111110.10011000, which in decimal is10.57.126.152. References: Ericsson IP Networking - IP Addressing, Software Installation and Upgrade Overview (Junos OS)
NEW QUESTION # 44
What is an important difference between OSPF and IS-IS?
- A. OSPF runs directly on Ethernet, while IS-IS runs directly on IP.
- B. OSPF is a distance vector protocol, while IS-IS is a link state protocol.
- C. OSPF runs directly on IP, while IS-IS runs directly on Ethernet.
- D. OSPF is a link state protocol, while IS-IS is a distance vector protocol.
Answer: C
Explanation:
Explanation
OSPF runs directly on IP, while IS-IS runs directly on Ethernet. This means that OSPF uses IP addresses to identify routers and links, while IS-IS uses MAC addresses or other link-layer identifiers. OSPF also requires an IP header for each packet, while IS-IS does not. Both OSPF and IS-IS are link state protocols, which means that they flood information about the network topology to all routers in the same area or domain. References: Ericsson IP Networking - Routing Protocols, Ericsson Router 6000 Series - Ericsson
NEW QUESTION # 45
Which operating system is used in Ericsson Router 6000 products?
- A. ERS
- B. Junos
- C. ERS
- D. IPOS
- E. SE-OS
Answer: A
Explanation:
Explanation
The operating system used in Ericsson Router 6000 products is ERS (Ericsson Router Software). ERS is based on IPOS (IP Operating System), which is a common operating system for Ericsson's IP portfolio. ERS provides advanced features and functionality for IP transport, such as MPLS, Segment Routing, QoS, IPSec, synchronization, SDN, and more. ERS also supports seamless integration with Ericsson Radio System and Ericsson Network Manager.
References: Router 6000 Series - Ericsson, Router 6675 Datasheet - Winncom
NEW QUESTION # 46
In an Ethernet frame carrying a VLAN tag, where does the VLAN tag appear?
- A. after the length field
- B. after the type field
- C. before the length field
- D. before the type field
Answer: D
Explanation:
Explanation
In an Ethernet frame carrying a VLAN tag, the VLAN tag appears before the type field. A VLAN tag is a
4-byte field that is inserted into an Ethernet frame to indicate the VLAN membership and priority of the frame.
The VLAN tag consists of two subfields: the tag protocol identifier (TPID) and the tag control information (TCI). The TPID subfield is a 16-bit field that identifies the frame as an IEEE 802.1Q-tagged frame, with a value of 0x8100. The TCI subfield is a 16-bit field that contains the priority code point (PCP), the drop eligible indicator (DEI), and the VLAN identifier (VID). The VLAN tag appears between the source MAC address and the type fields of the original frame, shifting the type field by four bytes. The type field indicates the type of the payload, such as IP or ARP .
References: [IEEE 802.1Q - Wikipedia], [VLAN Tagging Explained with DTP Protocol - GeeksforGeeks]
NEW QUESTION # 47
What is the purpose of penultimate hop popping?
- A. to reduce the load on the LER
- B. to reduce the load on the LSR
- C. to reduce the load on the LSP
- D. to reduce the load on the LDP
Answer: A
Explanation:
Explanation
Penultimate hop popping (PHP) is a function performed by certain routers in an MPLS enabled network. It refers to the process whereby the outermost label of an MPLS tagged packet is removed by a label switch router (LSR) before the packet is passed to an adjacent label edge router (LER). The purpose of PHP is to reduce the load on the LER, as it saves one cycle of label lookup. The LER can forward the packet based on its IP header or another label in the stack, without having to process the outer label. PHPfunctionality is achieved by the LER advertising a label with a value of 3 to its neighbors. This label is defined as "implicit-null" and informs the neighboring LSRs to perform PHP12.
References: Penultimate hop popping - Wikipedia, MPLS Penultimate hop popping - NetworkLessons.com
NEW QUESTION # 48
How do peers recognize each other's ability to use MP-BGP extensions?
- A. They advertise the ability using the capabilities field in the update packet.
- B. They advertise the ability using the capabilities field during the session establishment.
- C. They advertise the ability using the capabilities field in the hello packet.
- D. They advertise the ability using the capabilities field in the End-of-RIB marker.
Answer: B
Explanation:
Explanation
Peers recognize each other's ability to use MP-BGP extensions by advertising the ability using the capabilities field during the session establishment. MP-BGP is an extension to BGP that allows BGP to carry routing information for multiple network layer protocols, such as IPv6, VPNv4, multicast, etc. To support MP-BGP, peers need to exchange their capabilities during the session establishment phase, which consists of three steps:
open, keepalive, and update. In the open message, peers can include an optional parameter called capabilities, which indicates what kind of address families and subsequent address families they can support. If both peers agree on a common set of capabilities, they can proceed to exchange routing information for those address families using update messages56.
References: Use of MP-BGP Extensions for IPv6 Interdomain Routing, MP-EBGP Configuration Example - Cisco
NEW QUESTION # 49
......
